Detailed Technical Specifications
Working Area & Axis Travel:
X-Axis Working Area: 1,300 mm (51 inches)
Y-Axis Working Area: 2,500 mm (98 inches)
Z-Axis Travel (Clearance): 200 mm (7.8 inches)
Spindle & Performance:
Spindle Power: 4.5 kW / 6.0 kW high-frequency liquid-cooled spindle
Spindle Speed: 1,000 to 24,000 RPM
Tool Holder / Collet: ER32 precision collet chuck
Drive & Motion System:
Motion Actuators: High-performance AC servo motors and drivers on all axes
Transmission System: High-precision helical rack and pinion drive on X and Y axes, with precision ball screws on the Z-axis
Guide Rails: Heavy-duty 25 mm profile linear guide rails
Control Unit & Interface:
Controller: Integrated industrial CNC control system with a large full-color touchscreen display console

Control Panel Features: Physical emergency stop (E-stop) mushroom button, cycle start/hold buttons, and a manual rotary feed rat adjustment jog dial

Data Transmission: USB port and Ethernet network connection
Table & Dust Management:
Table Construction: Multi-zone vacuum hold-down table combined with T-slot aluminum tracks for mechanical clamping versatility
Dust Extraction: High-flow dust collection hood connected via a flexible overhead extraction hose directly above the spindle
Electrical & Operational Requirements:
Power Supply: 3-Phase, 380V / 50Hz (or customizable configuration)
Total Power Consumption: Approx. 6.5 kW
Machine Weight: Approx. 850 kg

Why Choose MicronUP?

• Ultra-precise machinery tailored for professional engineering projects and workshops.
• Genuine accessories and replacement parts supplied directly from our Korea headquarters.
• Secure hydraulic packaging ensuring safe delivery of machinery worldwide.
